EC110B Portable Conductivity Meter-Bioda

Conductivity Range:0.00 μS/cm to 100 mS/cm

Conductivity Accuracy:±1.0% FS

Inputs Conductivity:5-pin aviation connector

Power:Rechargeable Lithium battery, AC Adapter, 100-240V AC input, DC5V output

Conductivity Meter.png

EC110B Portable Conductivity Meter

GENERAL FEATURES

² LCD display screen, 3.5 inches.

² Reset feature automatically resumes all settings back to factory default options.

² Auto-power off feature effectively extends the battery service life.

² IP65 waterproof.

² Cell constant is settable

² Manual temperature compensation ensures accurate results.

PRODUCT SPECIFICATIONS

Model		EC110B
Parameters		EC
Conductivity	Range	0.00 μS/cm to 100 mS/cm
	Resolution	0.01 μS/cm minimum, various with range selection
	Accuracy	±1.0% FS
	Reference Temperature	25 ºC
Measurement	Reading Mode	Continuous
	Reading Prompts	Reading, Stable
	Temp. Compensation	MTC
Inputs	Conductivity	5-pin aviation connector
Display options	Backlight	Yes
	Auto Shutdown	300, 600, 1200, 1800, 3600 sec., off
	IP Rating	IP65
General	Power	Rechargeable Lithium battery, AC Adapter, 100-240V AC input, DC5V output
	Dimensions	80×255×35 mm
	Weight	400g (0.88 lb)
